Smart Grid Digital Solutions AI Camera

This device is mainly used for online inspection of transmission lines and early warning of potential hazards such as construction machinery damaging lines, hill fires and foreign objects on transmission lines.

It is equipped with infrared thermal imaging lens can achieve transmission line channel long-distance fire detection. Power tower and line body important parts of the close distance temperature sensing.

Product application

Key function

Main Specifications

Whole machine description

Complete machine configuration

PTZ Structure

Double barrel coaxial structure, the left barrel carries thermal imaging lens; the right barrel carries optical zoom camera

camera + wide-angle camera + infrared fill light + intelligent wiper + defogging device;

Base

General light + night vision dual-channel lens + down-view HD lens; base can be configured with Mac

The base line includes: power supply, sound and light alarm, 485 interface, network port;

Scalability

Expandable tower tilt module, AI intelligent analysis module, encryption module, audible and visual alarms module, Micro weather sensor (split type), 433 wireless sensor module

Cloud Terrace Unit

Wide angle lens

F3.1, Field of view: 132° (D) 112° (H) 61° (V), 2.0 megapixels

Zoom camera

Lens

20x (HY26X), 2.0 megapixels;

40x (QC30X,HY33X,LY30X), 2 megapixels; 30x (LY31 self-research), 8 megapixels, etc.

Thermal imaging lens

Resolution

640×512

Wave length

12μm

NETD thermal

sensitivity

40mK(@25℃ F1.0)

Lens

Support 35mm/50mm

Strong light protection

Support against sun damage

Interface

Network port

Cloud Platform Structure

PTZ

Support horizontal 360°, vertical -90° ~ +90° rotation, no monitoring blind spot

Preset position

≥255 units

Smart wiper

Support

Glass heating

Support

Base unit

Day vision camera

Image sensor 1/3.1'', 16 megapixels, dual channel support

Night vision camera

Image sensor 1/2'', 2.0 megapixels, dual channel support

Angle adjustment

Manual vertical -90 ° ~ 90 ° adjustment, to meet the transmission line channel up and down the slope of the field of view range Adjustment monitoring needs

Down-view lens

Image sensor 1/3.1'', 16 megapixels

External interface

Support DC12V interface, USB interface, SIM card interface, network port, RS485 interface, TF card interface, audio and visual alarm interface TF card interface, audible and visual alarm interface

Terminal

basic functions

Performance

Visible light function

PIP function

When configured with a wide-angle lens, it supports binocular PIP to control the whole picture and take into account the details.

Operating principle

Customizable setting of shooting interval, front-end analysis of pictures taken by the device, immediate return to the platform after identifying the danger, and regular return when there is no hidden danger

Video features

Support continuous real-time video and continuous terminal recording

Automatic line patrol

The device can automatically patrol along the line direction

Intelligent analytics

Should have the front-end intelligent analysis function, identify objects including cranes, tower cranes and other mechanical vehicles, smoke, fire points, wire foreign objects, etc.

Point cloud ranging

Combine with UAV point cloud data to realize the channel camera to identify the outer break and measure the distance.

PTZ control

Support PTZ control one-touch focus function

Thermal imaging function

Dual light fusion

Support automatic superimposition of thermal imaging images on the zoom screen.

Support framing and superimposing thermal imaging data to the zoom screen to enhance the reality effect.

Display mode

Should have white heat, black heat, pseudo-color (iron red / rainbow, etc.) a variety of display modes

Temperature tracking

The thermal imaging screen shows the maximum temperature , the minimum temperature , and the temperature at the center of the screen at three points.

Alarm limits

High and low temperature thresholds can be set according to actual needs.

Terminal Function

Communication requirements

4G all-access, APN dedicated access network

Status management

Monitoring, management and storage functions for the operating status of monitoring devices

Power management

Battery power management, the terminal according to the power to work mode switching, to protect the online rate

Storage function

Front-end picture/video storage, storage capacity: 64G, 128G two configurations

Wireless debugging

Should support short-range wireless transmission debugging mode, real time control and debugging of the device

Protection level

Waterproof and dustproof rating IP67

Shell material

Made of die-cast aluminum, sturdy and durable

Mounting bracket

Stainless steel, fasteners are hot-dip galvanized, adaptable to angle steel towers, cement poles, steel pipes Different types of poles (towers)

Power supply system

Solar panels

Standard: 2X90W. From 90W to 360W depending on battery capacity configuration.

Battery

Standard: 100AH lithium iron phosphate, according to the local temperature to choose the battery, lithium iron phosphate

Battery, etc., capacity can be selected 50AH,100AH,200AH,300AH

Sunless operating time(Battery fully charged)

20 days

Projects Reference Configuration

Tower tilt

Inclination measurement range: biaxial -10°~+10° (optional -30°

~+30°, -60°~+60° or -90°~+90°); Inclination measurement error:

≤±0.05°; Inclination measurement resolution: ±0.01°

Micro Weather module (Three combinations available)

Wind speed

Wind direction

Temperature

Humidity

Atmospheric pressure

Rainfall

4 Elements

√

√

√

√

5 Elements

√

√

√

√

√

6 Elements

√

√

√

√

√

√

Technical Parameter

Micro Weather

Name

Measurement Range

Error Range

Resolution

Temperature

-30℃～+85℃

±0.5℃

0.1℃

Humidity

0～100%

±4%RH

1%RH

Wind speed

0～75m/s

±(0.3+0.03V)m/s

0.1m/s

Wind direction

0～360°

±3°

0.5°

Rainfall

0～4mm/min

±0.4mm (when ≤10mm)

±4% (when >10mm)

0.2mm

Atmospheric pressure

0～100%

±4%RH

0.1hPa

Audible and visual alarms

Alarms can be heard within 200 meters and can clearly distinguish the voice content, can see the obvious light.

Actual effect
