Rugged Tablet With 2D Barcode Scanner

Rugged Tablet With 2D Barcode Scanner

SENTER ST907V3.0 Rugged Tablet Android 7.1 OS, Octa core, 2Ghz CPU Rugged Tablet PC with 4G LTE Optional functions: LF/NFC/UHF RFID reader, 1D/2D bar code scanner ST907V3.0 Rugged Tablet PC with Octa-core, Sigle SIM and 4G communication. It is with 1280*800dpi high resolution, 8" touch...

Product Details

SENTER ST907V3.0 Rugged Tablet

Android 7.1 OS, Octa core, 2Ghz CPU Rugged Tablet PC with 4G LTE

Optional functions: LF/NFC/UHF RFID reader,  1D/2D  bar code scanner

ST907V3.0 Rugged Tablet PC with Octa-core, Sigle SIM and 4G communication. It is with 1280*800dpi high resolution, 8" touch screen,  Android 7.1 OS. 1D/2D barcode reader,LF, NFC UHF RFID are optional. Support Dual Bands WIFI, Bluetooth, GPS+BDS+Glonass and other functions. Product specification






OVERVIEW

ST907V3.0 industrial tablet PC adopts Octa core 2GHz CPU and Android 7.1 operation system; LCD screen is readable under sunlight; can configure barcode scanning, RFID reader as well as other information acquisition module; has super long battery life; IP67 high reliable three-proof structure water/dust proof; drop resistance from 1.2m.



KEY FEATURE

-- Android 7.1 operating system; CPU MSM8953, 8 core, 2GHz CPU; RAM 4GB ROM 64GB, Micro SD 128G

-- Three-proof design: IP67 three protection grade, drop resistance from 1.2m

-- Visible under strong light;8 inch LCD screen, 1280*800 (Optional:1920x1200) IPS capacitive touch screen

- Powerful function: multi function information acquisition configuration (1D/2D bar code scanning, LF/HF/UHF RFID reader)

-- Multi communication modes: support 4G, WIFI, Bluetooth and many wireless communication modes

-- Strong battery life: 10000mAh Lithium Battery

-- Certificates: CCC/CE/ROSH/FCC/IP67/MIL-STD-810

-- Docking Station: Make the tablet charging easier




Product Description

  SPECIFICATIONS

Standard function

Operating System

Android 7.1

CPU

MSM8953, 8 core CPU, 2GHz

GPU

Qualcomm® Adreno™ 506 GPU,650Mhz

RAM

RAM: 4GB

FLASH: 64GB

Extended Storage

Micro SD, Maximum 128G

USB port

5 pin MicroUSB; Support to connect U-disk/Mouse/Keyboard/OTG line

OTG

Through OTG can meet 100M network port, network card setup, PPPoE dial-up, web browsing. Support OTG extend RS232 serial port/485 serial port/RJ45 Serial port

External port

Charge port, headphone port

Protection Grade

Industrial Protection Grade

IP67

Drop Grade

Drop resistance from 1.2m

Wireless Communication

Bluetooth

Support 4.1

GPS

GPS+BDS+A-GPS+GLONASS

High precise GPS: NE0-6M

GPS+BDS: NEO-M8N

GPS+GOLNESS: NEO-M8N Accuracy 4m

WIFI

Support IEEE 802.11a/b/g/n/ac (2.4G and 5G bands)

2G/3G/4G LTE

GSM 850/900/1800/1900   B5/B8/B3/B2

WCDMA 2100/1900/1700   B1/B2/B4

TD-SCDMA B34/B39

FDD-LTE: B1/B3/B5/B7/B8  2100/1800/850/2600/900

TDD-LTE : B38/B39/B41/B40/

Band38:2570 MHz - 2620 MHz

Band39: 1880 MHz - 1920 MHz

B41:2555-2655MHz

B40/:2300-2400MHz

Physical Parameters

Display Screen

8 inch LCD screen,1280*800 (Optional 1920*1200) IPS screen, capacitive touch screen

Keyboard

Android menu, Homepage, Return, Volume, Barcode, ON/OFF, Reset

Camera

5 million pixels front camera, 13 million pixels rear camera with automatic focus and lighting function

Headset

3.5mm audio Interface, has MIC and Single loudspeaker

     LED indicator light

Support (ordinary flicker, Call fast flicker, missed calls, charge indicator)

      Flashlight Function

Support, can be used for emergency lighting

Googleplay store

Support

Gravity Sensor

Support

        Compass

Support

Acceleration sensors

Support

Magnetometer

Support

Light and distance sensor

Support

Vibrating motor

Support

FM

Support

Rechargeable Lithium Battery

3.8V, 10000mAh

Standby

About 500 hours

Working time

About 8 hours

Dimension

232*158*22

Weight

810g

Environmental Characteristics

Working Temperature

-10℃ ~ +50℃

Storage Temperature

-40℃ ~ +60℃

Humidity

5%-95% relative humidity; no condensation

Optional function

Far infrared meter reading

Working frequency 37.9K

Barcode Scanning

1D Laser Scanner Index(Internal):

Honeywell N4313 or Zebra EM1350

Scanning speed: 104 times/second+12 times/second (two way scanning)

Scanning distance: 2.5cm-114.3cm

Scanning angle: 47±3°(default) /35±3°(reduced code)

2D Barcode Scanner Index(Internal):

Newlands EM3096

Honeywell N3680

Motorola SE4750

Identification ability: 1D, 2D, OCR

Scanning angle: rotate 360°, incline±50°, deflection ±50°

Field of View: Horizontal 36°, vertical 23°

Depth of field: 4cm-23.5cm

Environmental luminance: 0~100,000 LUX

RFID

HF RFID(Internal):

Support NFC/NXP, 13.56MHZ ISO14443A,B and ISO15693 protocol, reading distance 0-3cm, Tag support type:SR176,SRIX4K(TYPE-B),I-Code2,TI RFID Tag-it HF-I,EM4034,Mifare Classic ETC

LF RFID:

134.2KHZ LF RFID, support ISO11784/5 protocol, support to read EM, TEMID, TK cards and compatible cards IC card(FDX/HDX)

125KHZ LF RFID, support to read ID card

UHF RFID



Internal

Ray links RLM060 or ThingMagic M6E-NANO American Standard, EPC C1 GEN2/ISO 18000-6C,output power 10dBm-30dBm

Reading distance: 1m

Ceramic antenna: 0.3db(25*25*4mm)

External

Supports EPC C1 GEN2/ ISO 18000-6C and ISO 18000-6B/6C protocol

Reading distance:1.8m/3.5m

Frenquency:865-868Mhz or 920-925Mhz

Ceramic antenna: 0.3db(25*25*4mm)













APPLICATIONS

This advanced industrialgrade mobile information terminal can been widely used in mobile informatization projects of various industries, for example inspection, electric power, communication, gas, water affairs, logistics, medical treatment, government affairs, police affairs, forestry, traceability and other fields.



VIIDEO LINKS ON YOUTUBE

Three-proof: https://youtu.be/r3RCxftqL5Y

Fingerprint Reading: https://youtu.be/xpUhzqALM5o

Brief introduction of ST907V3.0: https://youtu.be/-10daENaJ0E

ST907V3.0 RFID Tag Reader: https://youtu.be/EkbV3SimG3s

ST907V3.0 1D/2D barcode scanner: https://youtu.be/wB3TKVXLrpE

Vehicle mount of ST907V3.0: https://youtu.be/htxUntbpT_4



Our Services




Packaging & Shipping


FAQ

Q1: Does the  IP67 Rugged handheld Tablet PC can read QR code and common 1d bar codes? Support UHF RFID Europe standard?

A1: Yes, if choose 2d scan version, it can read both 1D common code and 2d codes such as QR, PDF417, Data Matrix, PDF417 code...

Yes,support America and Europe UHF RFID Standard.

 Q2: What is your payment term?

A2: We accept T/T, Western Union, Paypal, Escrow.

 Q3: Do you offer OEM service?

A3: OEM service is available in our factory, Could you tell us which is suitable for you please: special design, customize specification, logo silk print or customize retail boxes? But for OEM, we would require MOQ 100-500 units according to your OEM requirements.

 Q4: Can i get a sample to test with a good price?

A4:Yes ! every clients with one time opportunitiy to get a sample with the same price for big order
