Transmission Line Protection AI Thermal Camera

ST2303B/S V6.0P-F thermal imaging PTZ AI Inspection devise:
1.Supports intelligent monitoring of fire point
2.Supports infrared temperature measurement and alarm for temperature abnormality

Send Inquiry

Product Introduction

Product Features

Power line inspection Thermal camera:

It supports intelligent monitoring of fire point,

2. It supports infrared temperature measurement and alarm for temperature abnormality;

3. It supports the function of thermal imaging and visible light linkage.

Product application

fire-ravaging-nature-landscape23-2150789341

01.

Fire-prone areas, suitable for effective identification of hill fires

02.

Monitoring the temperature change of insulators and clamps, and at the same time have the line channel alarm warning function

Key function

Dual optical fusion monitoring

Visible light image AI recognition + infrared thermal imaging dual-spectrum temperature recognition, more accurate recognition.Support for infrared temperature measurement, temperature abnormal alarm

Infrared protection mechanism

The infrared thermal imaging camera adopts anti-scorch design, effectively guaranteeing real-time and reliable monitoring of the transmission channel.

Extended function

Expandable micro-weather and tower tilt sensors for data aggregation and processing.

Passive wireless

And the equipment through the solar panel plus battery power supply, wireless 4G transmission, no external power supply and communication module.

Main Specifications

Projects Technical parameters
Camera	Thermal lens	Vanadium oxide uncooled detector with a resolution of not less than 384*288
	Day view lens	16 megapixel HD lens Lens angle of view: diagonal/horizontal/vertical: 76 /64 /50° respectively
	Night vision lens	2 megapixel starlight-grade low- light lens Lens angle of view: diagonal/horizontal/vertical ：105°/88°/48° respectively
	PTZ Optical Zoom lens	Optical zoom: standard: 20-40x , 2 megapixel Horizontal field of view: 56.9-2.9 degrees (wide angle - telescopic) Close up distance: 100m-1500mm (wide angle - telescopic) Minimum illumination: 0.001Lux/F1.5 (color)/0.005Lux/F1.5 (black and white)
		Horizontal direction: 360° multi-turn infinite position Vertical direction: -90°～+90° With 256 preset positions Support wiper
Operating Principle		Customizable shooting interval, the front end of the device analyzes the shooting pictures, and immediately returns to the platform after identifying the danger, and regularly returns when there is no hidden danger
MTBF		≧30000 Hours
Checking and commissioning		Can be checked and tuned without disassembling the machine
Protection level		IP67
Weight		52Kg(Host+external battery + solar panel + bracket)
Sunless operating time(Battery fully charged)		20 days
Power supply method		Solar panel plus battery: 18V90W/12.8V50AH
Minimum Illumination		≤0.001Lux/f1.2
Storage Capacity		SD card 128g/256g
Camera adjustability		Omni-directional manual adjustment according to line direction

Operating temperature	-40℃～+70℃
Service life of the whole machine	Not less than 5 years
Power consumption	Online state average static power consumption 0.04W, average acquisition power consumption 0.74W, peak power consumption 9.9W
Host case material	Aluminum alloy
Front Analysis	Support Senter front-end analysis module
