OTDR 5.6inch 1310/1550nm 32/30db

If you're in need of otdr 5.6inch 1310/1550nm 32/30db to help with your business, please be free to buy with our factory. As one of the leading such manufacturers in China, we will offer you low price and unmatched services.



SENTER ST3200D OTDR 1310/1550nm 32/30db

ST3200D 1310/1550nm 32/30db is a high quality, multifunctional smart OTDR supports many optical fiber testing functions, such as: otdr, optical power meter, stable light source, vision fault locator, optical fiber loss test and iOLM/ event map. Key button mode and touch screen operation mode optional.

Model	ST3200D
OTDR
Fiber Type	G.652
Wavelength	1310nm±20nm/1550nm±20nm
Dynamic Range	32dB/30dB
Event Blind Zone	1m
ATT Blind zone	6m
Test Range	500m/1 km/2km/4km/8km/16km/ 32km/64km/12 8km/256km
Pulse Width	5ns/10ns/30ns/50ns/80ns/160ns/320ns/500ns/800ns/1000ns/3000ns/5000ns/8000ns/10000ns/20000ns
Ranging accuracy	±( 0.75m+ Sample interval +0.005 % x Test distance)
Loss accuracy	±0.05dB/dB
Sample Points	16k〜256k
Sample Resolution	0.05m~16m
Reflection Accuracy	±3dB
File Format	SOR Standard File Format
Loss Analysis	4-point method /5-point method
Laser Safety Level	Class II











Refresh Rate	3Hz(Typ.)
Data Storage	Internal storage： 100M (<3000 curves) ； External： 4G bit
Connector	FC/UPC (Interchangeable SC、ST)
Data Interface	USB、Mini-USB、10M/100M Ethernet Port
OPM
Wavelength range	800nm~1700nm
Connector	Universal joint FC/SC/ST
Test Scope	-50dBm〜+26dBm
Uncertainty	±5%
Calibration Wavelength	850nm/980nm/1300nm/1310nm/1490mn/1550nm/1625mn/1650nm
LS
Wavelength	Consistent with OTDR output wavelength
Output Power	≥-5dBm
Stability	CW, ±0.5dB/15min (Test after 15 minutes of boot-up preheating)
Connector	FC/UPC (Interchangeable SC、ST)
VFL
Wavelength	650nm±20nm
Output power	≥2mW
Mode	CW/lHz/2Hz
Connector	FC/SC/ST

Others
Display	5.6 inch color LCD + touch screen
Power Supply	AC/DC Adapter： Input： 100V〜240V, 50/60Hz, 0.6A Output： 12V-19V, 1.5A Li-Battery： 7.4V, 5200mAh
Battery working hours	≥10h
Operating Temperature	-10°C 〜+50°C
Storage Temperature	-40°C 〜+70°C
Relative Humidity	0 〜95 %, Non Condensing
Weight	≤1.2kg
Size	208/mmx 110mmx56mm

Our company has rich experienced professional team and is committed to providing customers with reliable solution and satisfactory services. Through continuous development and expansion of our company, we now have customer around the world, especially in North America, South America, Europe, and Asia. Our products and services have been well received by customers. In the future, we will continue to provide customers with safe and reliable FTTX solutions.

FAQ

Q1: When can I get the quotation back?

A:Generally, quotes will be replied within 24 hours or faster(weekends not included), however, a few of days would be taken for special ones.

Q2:How about the cable's quality ?

A: Our factory has dug in this industry for many years and sold to many countries in the world. We have a series of professional equipment and manufacturing instruments to make sure reliable quality of our products.

Q3: How do l assure that you are a reliable supplier?

A: We are the Assessed Supplier of Alibaba.com. Alibaba as the third party to verify our factory and office to confirm we are a real and reliable supplier. If you are willing to verify that through the phone or video, you are welcome at any time.

Q4: Could the OEM be accepted and what's the MOQ?

A: Of course, your customization order is always welcomed. The MOQ Depends on different items, each item has its own minimum quantity. Your satisfaction is our maximum motivation.
