Ultra-thin Rugged Tablet
S917 8 inch Ultra-thin rugged tablet.
Its supports Android 8.1 os,3G RAM 32G ROM,octa core 2.2GHZ,WIFI,GPS,BT4.0,IP65,4g LTE,hand strap,fingerprint unlock,etc
At same time,1D/2D barcode scanner,Long distance UHF RFID reader is optional.
Send Inquiry
Product Introduction
S917 Ultra-thin Rugged Tablet
Advanced system
Android 8.1 operating system; Qualcomm, 8 core, 1.8GHz CPU/A53
Visible under strong light
8 inch LCD screen, 1920x1200 IPS; Multi communication modes; 3G/4G, WIFI, Bluetooth, dual SIM card
Certification
CCC/CE/ROSH/FCC/IP65/MIL-STD-810
Optional function
Multifunction1D/2D bar code scanning; HF/UHF RFID reader;
Fingerprint identification(Front); High precise GPS
Wireless Charging
Dual SIM cards
OVERVIEW
S917 industrial tablet PC adopts Octa core 2.2GHz CPU and Android 8.1 operation system; LCD screen is readable under sunlight; can configure barcode scanning, RFID reader as well as other information acquisition module; has super long battery life; IP65 high reliable three-proof structure water/dust proof; drop resistance from 1.2m.
Standard Configuration
Operate system | Android 8.1 |
CPU | Qualcomm SD630,CPU 1.8GHz/A53 Qcta core |
GPU | Qualcomm® Adreno™ 508GPU |
RAM | RAM:4G FLASH:64G |
Extended Storage | Micro SD, Maximum 128G |
Headphone | 3.5mm audio Interface, has MIC and dual loudspeaker |
USB port | 5 pin MicroUSB; Support to connect U-disk/Mouse/Keyboard/OTG line |
OTG | OTG extend RS232 serial port/485 serial port/RJ45 Serial port |
Sensor | Gravity sensor, Compass, Acceleration and gyroscope sensors, Light and distance sensor |
Industrial Protection Grade | IP65 ,Drop resistance from 1.2m |
Fingerprint | Front fingerprint identification (fingerprint unlocking) |
Environmental Characteristics | Working:-20℃ ~ +55℃ Storage:-40℃ ~ +60℃ 5%-95% relative humidity; no condensation |
Communication model | --802.11a/b/g/n/ac (2.4G and 5G bands) --Bluetooth 4.0 --GPS+BDS+A-GPS+GLONASS,10m --High precise GPS: GPS+BDS 3-5m --2G/3G/4G 4G LTE: LTEB1/B3/B5/B7/B8/B20/B26/B34/B38/B39/B40/B41 WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8 TD-SDMA: 34/39 CDMA 1X/EVDO:BC0 |
Display Screen | 8 inch LCD screen,1920*1200 IPS screen, capacitive touch screen |
Keyboard | Android menu, Homepage, Return, Volume+/-, Barcode, ON/OFF |
Camera | Front: 5MP Rear: 13MP with automatic focus and lighting function |
Rechargeable Lithium Battery | 3.8V, 6000mAh; Standby about 500 hours Support Qi protocol wireless charging and USB QC3.0 fast charge. |
Google play | Support |
Size | 229.4*136.2*11.5mm 510g |
Optional Configuration
Far infrared meter reading | Working frequency 37.9K |
Barcode Scanning | 1D Laser Scanner Index(In Jacket): Honeywell N4313 or Zebra EM1350 Scanning speed: 104 times/second+12 times/second (two way scanning) Scanning distance: 2.5cm-114.3cm Scanning angle: 47±3°(default) /35±3°(reduced code) |
2D Barcode Scanner Index(In Jacket): Newlands EM3096 Or Honeywell N3680 Identification ability: 1D, 2D, OCR Scanning angle: rotate 360°, incline±50°, deflection ±50° Field of View: Horizontal 36°, vertical 23° Depth of field: 4cm-23.5cm Environmental luminance: 0~100,000 LUX | |
2D Barcode Scanner Index(In Host): Zebra SE2100 | |
RFID | HF RFID(In Host):Support Mifare Classic 1 card |
UHF RFID(In Jacket): Supports EPC C1 GEN2/ ISO 18000-6C and ISO 18000-6B/6C protocol Reading distance:1.8m/3.5m Frenquency:865-868Mhz or 920-925Mhz Ceramic antenna: 0.3db(25*25*4mm) |
Please visit https://youtu.be/q40nuRckkw0 for the video
KEY FEATURE
-- Android 8.1 operating system; CPU MSM8953, 8 core, 2.2GHz CPU; RAM 4GB ROM 64GB, Micro SD 128G
-- Three-proof design: IP65 three protection grade, drop resistance from 1.2m
-- Visible under strong light;8 inch LCD screen, 1920x1200IPS capacitive touch screen
--Powerful function: multi function information acquisition configuration (1D/2D bar code scanning, HF/UHF RFID reader,dual SIM card)
-- Fingerprint unlock
-- Multi communication modes: support 4G, WIFI, Bluetooth and many wireless communication modes
-- Strong battery life: 6000mAh Lithium Battery
-- Certificates: CCC/CE/ROSH/FCC/IP65/MIL-STD-810
-- Docking Station: Make the tablet charging easier
APPLICATIONS
This advanced industrialgrade mobile information terminal can been widely used in mobile informatization projects of various industries, for example inspection, electric power, communication, gas, water affairs, logistics, medical treatment, government affairs, police affairs, forestry, traceability and other fields.
Looking to the global era for technological change, we are constantly expanding IOT solutions in various industries. We strive to seek excellent suppliers, agents, channels and other partners from all over the world to jointly establish a fair and mutual trust cooperation platform, and work with them to create sustainable value for customers in the industry.
We provide partners with the industry's best products and the most close to the needs of users of the solution, with the most attractive incentive policies and cooperation programs, to help you seek to explore market opportunities, transfer them into the actual value and inject long lasting brand industry influence. Our considerate after-sales services and quality assurance system will help you solve all your worries when facing customers. We are willing to join hands with you to achieve success in the development of the Internet of things(IOT) industry.
Q :Are you manufacturer?
Yes, we are manufacturers.We can provide OEM / ODM customized service according to our customers’ various application and
demands.All of our products are fully patented, ID/MD design, hardware and software,mold,assembly are done by our own team.
Q: Would you provide SDK for me?
Yes, we offer free SDK if you order sample.In addition, we also have support engineers to assist you with software development.
Q: What is the minimum order(MOQ)?
We accept one unit for standard products.we can even customized with your logo if needed. If require OEM, will see detailed
requirements and confirm MOQ to you from our sales department.
Q: Can we get the free sample?
Sorry, generally we would not provide the free sample. If the customer confirm the specification and price, they can order the
sample firstly for the testing and evaluation.
Q: Can i choose multiple function into 1 device?
A: Yes, you can choose multiple fuction into onedevice, Different functions depending on the product model,optional functions:RFID
(LF/HF/UHF)1 Fingerprint/ Bar code scanner.You also can choose rugged tablet only without optional functions
Q: How to order and pay?
A: We accept T/T (bank transfer), Alibaba online,Western Union 1 Trade Assurance
Q: What's Your Products Warranty?
A: We Offer 12 month Warranty after shipment sent.
Q: Can I extend the warranty?
A: We offer a deferred warranty for up to 24month or 36 Months, and the price for the warranty extension is 5% 10% up.
Q: How long it will take for delivery?
A: For production lead time around 3-10days depend on requirement, and shipping time by DHL/UPS/FEDEX/TNT, delivery time would
around 3-5 working days. For some remote place, delivery time maybe a little bit longer.
Q:How to repair the device if any problem ?
A: We will provide technical support online to solve problem; If for the hardware problem , we couldsend the parts or components
and teach customer to fit if they have technician or can also send backto us to fix it.
Q: Can you do customized and preload our software?
We are professional rugged device manufacture with more than 25 years experiences
