RFID reader handheld terminal
√ Android 9.0 OS+8-core 2.0GHz CPU+
√ more High-speed, multi-tasking
√ 4.7 inch ultra speed scanner
√ Equipped with high-performance UHF reading and writing module
Commit to be an internationally renowned industry IoT solution provider
As a leader of industrial IoT in China, Shandong SENTER Electronic Co, LTD is a trustworthy IoT manufacture of products and solutions of mobile IoT terminals, communication test terminals and power transmission line inspection terminals. With 26 years of development history, we are devoted to empowering the front line of business, raise efficiency of manufacture, and create a smarter life for everyone.
| Key Features | |||||||||||||
| Specifications | |||||||||||||
| Product Description | Data communication | ||||||||||||
| CPU | Octa Core 64-bit 2.0GHz high-performance processor | WIFI | Dual -band 2.4GHz/5GHz, Supporting IEEE 802 a/b/g/n/ac protpcol | ||||||||||
| RAM+ROM | 2GB+16GB ; 4GB+64GB(optional) | WWAN | 2G: GSM:B2/3/5/8 | ||||||||||
| SYSTEM | ANDROID 9.0 | 3G: WCDMA:B1/2/5/8 TDS:B34/39 | |||||||||||
| 4G: FDD _LTE:B1/3/4/7/8/20/12 | |||||||||||||
| TDD_ LTE:B34/38/39/40/41 | |||||||||||||
| Bluetooth | Support Bluetooth 5.0+BLE | ||||||||||||
| GNSS | Support Gps, Galileo, Glonass, Beidou | ||||||||||||
| Physical Parameter | Data collection | ||||||||||||
| Dimensions | 160*70* 20mm | UHF RFID (optional) | |||||||||||
| Weight | 290g （Depends on device function configuration) | Protocol | ISO18000-6C/EPC Class1 Gen2 | ||||||||||
| Display | 4.7" IPS color display,resolution800x480 | ||||||||||||
| Flashlight | 800mA flashlight | Working frequency | 920MHz~925MHz | ||||||||||
| Battery Capacity | Rechargeable polymer battery (3.8V4000MAh) | ||||||||||||
| Power output | 5~30dBm | ||||||||||||
| Executive standard: GB31241-2014 | |||||||||||||
| Lithium battery 3.6V power su pply, 5200mAh, detachable | Antenna Circular polarization antenna | ||||||||||||
| Reading distance | Up to 10m | ||||||||||||
| Vibrating motor | Built-in programmable vibration motor | ||||||||||||
| Reading rate | Up to 700tags/s | ||||||||||||
| Charging | Type-C charging and pin port charging, 18W fast charging | NFC(Optional) | |||||||||||
| Frequency | 13. 56MHz | ||||||||||||
| Audio | Built-in microphone | Protocol | Support ISO14443A/B, 15693 agreement | ||||||||||
| Sensor | G-Sensor/Proximity sensor/Light sensor | Distance | 0cm-3cm | ||||||||||
| Intercom function (optional) | Supporting one-button PTT calls | ||||||||||||
| Keyboard | 9 keys in total, front key*4, side scan key*2, side custom key*2, side power key*1 | ||||||||||||
| User Environment | |||||||||||||
| Operating Temperature | -20℃—60℃ | ||||||||||||
| Storage Temperature | -40℃—70℃ | ||||||||||||
| Environment Humidity | 0%RH--95%RH(no condensation) | ||||||||||||
| Drop Specification | 6 sides Supports 1.2 meters drops on the marble within the operating temperature | ||||||||||||
| Sealing | IP65 | ||||||||||||
| Accessories | |||||||||||||
Charger,Hand strap,Protective film,Battery Optional:Handle grip,Dock station,Small dock station,Dock station(Four) | |||||||||||||
| Application | |||||||||||||
 ● In the retail industry, in order to achieve a high -quality service experience, in addition to the waiter's patient service attitude, efficient information management is also very important. Store associates can use Senter handheld android PDA to scan products barcodes or RFID tags to promptly check details like the number of inventory, specifications, price, discount information, etc., which can better meet customer needs, improve work efficiency and accuracy of operations. |
 ● In the manufacturing industry, the production and transportation of items are a huge and complex process. Handheld PDA can improve efficiency and convenient. Its RFID technology can achieve inspection and control inventory. Mechanical maintenance, order tracking, and product tracking can be achieved to make the data better, thereby improving the work efficiency of workers. |
| Video | |||||||||||||
| Accessories | |||||||||||||
