ST801B Optical Multi Power Meter Tester With FC, ST, SC, LC
ST801B Optical Multi Power Meter With FC, ST, SC, LC
ST801B Optical Multi Power Meter With FC, ST, SC, LC
ST801B Optical Multi Power Meter With FC, ST, SC, LC
ST801B Optical Multi Power Meter With FC, ST, SC, LC
ST801B Optical Multi Power Meter With FC, ST, SC, LC

PON Power Meter

Combining optical source and optical power meter in one, Optical Power Multi Meter is a portable and intelligent instrument for optical network test. There are inner 1310nm and 1550nm dual wavelength and single output optical source. It can fulfill the functions of steady optical source and optical power meter at the same time, and it realizes the loop test and two-way automatic test. Its single-end test solution greatly advances the test efficiency. The inner microprocessor and linearity magnification technology ensure the long time calibration and test accuracy.

Send Inquiry

Product Introduction

Features:

For PON network testing.

Support online measurement.

Pass through measurement.

Fast assessment by PASS/FAIL function.

Display 1310/1490/1550 results in one screen.

One-year warranty and Three-year recommended calibration interval.

Key Features

Test 3 wavelengths: 1490nm, 1550nm, 1310nm

Suitable for all PON network :APON, BPON, EPON, GPON

UseThreshold Sets

Save and upload the records to computer through USB, 99 froups

Auto power off, auto backlight off, low voltage power off

Wavelength
Standard wavelengths		1310 (upward testing)	1490 (downward testing)	1550 (downward testing)
Pass zone(nm)		1260～1360	1470～1505	1535～1570
Range(dBm)		-40～+10	-45～+10	-45～+23
Isolation @1310nm(dB)			>40	>40
Isolation @1490nm(dB)		>40		>40
Isolation @1550nm(dB)		>40	>40
Accuracy
Uncertainty(dB)		±0.5
Polarization Dependent Loss (dB)		<±0.25
Linearity(dB)		±0.1
Through Insertion Loss(dB)		<1.5
Resolution		0.01dB
Unit		dBm / xW
General Specifications
Storage number	99 items
Auto backlight off time	30 seconds without any operation
Auto power off time	10 minutes without any operation
Battery	7.4V 1000mAH rechargeable Lithium battery or dry battery
Continuous working	18 h for rechargeable ; about 18 hours for AA battery too, but different for different battery brands
Working temperature	-10~60℃
Storage Temperature	-25~70℃
Dimension (mm)	2009043
Weight (g)	About 330

RAQ:

1. who are we?

We are based in Shandong, start from 1996,sell to European(60.00%),South America(30.00%), South East Asia(10.00% )There are total more than 500 people in our factory

2. how can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment;

3.what can you buy from us?

fast connector,patch cord,fiber optic distribution box,adapter,plc splitter

4. why should you buy from us not from other suppliers?

SENTER is a high and new technology enterprise that develops, produces and sells fiber optic and copper tester

Our Service:

1: Fast Delivery : 1-3 days

2. Delivery: Door to door DHL service

3. 12 months warranty

4. Whole Life Repair
