Android PDA

ST917M 4inch RFID Reader PDA Terminal:
Key Features:
√Android 10.0 system
√64-bit high-performance processor
√2D scanning engine Honeywell N6603 CM60 5703
√Barcode scanning, RFID reader, Fingerprint identification
√dual-band 2.4GHz/5GHz, 2G,3G,4G wireless communication
√GPS,NFC,IP66
Send Inquiry
Product Introduction



ST 917M

Key Features
Advanced System Android 10.0 operating system;64-bit high-performance processor;supporting dual-band 2.4GHz/5GHz, bluetooth 5.0, transmission distance 5-10 meters,GPS,Galileo, Glonass, Beidou
Powerful Function  OTG, gravity sensor, light sensor, proximity sensor, vibration motor,2D scanning engine Honeywell N6603 CM60 5703, 13MP HD rear camera,2MP color front camera, IP66, NFC,6 sides Supports 1.2 meters drops on the marble within the operating temperature.
Protection Level

IP67(IP67 standard refers to the level of protection safety. It defines the protection capacity of a liquid and solid particles in the interface.)


Specifications


  Performance


  Date Communication



SystemAndroid 10.0


WLANSupport IEEE 802.11a/b/g/n/ac
CPUCortex-A53 Octa-core 64 bit 2.0GHz high performance processor


BLUETOOTH  Support BT 5.0+BLE, transmission distance 5-10m
RAM+ROM4GB + 64GB


GNSSSupport GPS,Beidou, Glonass, A-GPS
Expand memoryType-C USB port; Support to connect U-disk/Mouse/Keyboard/OTG line


WWANGSM:B2/3/5/8
WCDMA:B1/2/5/8
TDSCDMA:B34/39
FDD_LTE:B1/3/4/7/8/20/12
TDD_LTE:B34/38/39/40/41
standard13MP HD camera,Support auto focus, Flash, Anti-shake, Macro shooting13MP HD camera,Support auto focus, Flash, Anti-shake, Macro shooting



  Physical Parameter


  Uesr Environment



Dimensions167*78.8*18.2


Opertain Temperature-20℃ ~ +60℃
Weight<300 (depending on equipment function configuration)


Storage Temperature-40℃ ~ +70℃
Keypad19 two-tone buttons, left button x1, right button x1


Environment Humidity5%-95% relative humidity; no condensation
Display4.0 " screen, 480×800 resolution


Drop Specification6 sides Supports 1.5 meters drops on the marble within the operating temperature
TPSupport multi-touch


Rolling test0.5m rolling for 6 sides, can still work steadily
Battery CapacityRechargeable polymer battery (3.8V 4500mAh)  removable



Protection SealingIP67
Communication Interface  Type-C 2.0 USB x 1, support OTG function POGO    Pin x 1



AudioSpeaker (mono), Microphone, Receiver,Flashlight


Expansion Card SlotNano SIM card X2, TF Card X1




SensorGravity sensor, light sensor, distance sensor, vibration motor





 Application

Our  industrial PDA can be used in logistics, retail and other fields:

 PDA Scanner .jpeg

●  According to different functions completed by the RFID system, the RFID system can be divided into four types, divided into electronic surveillance technology, portable data collection system, logistics control system, and positioning system. In the logistics control system, the fixed RFID reader is dispersed in a given area, and the reader is directly connected to the data management information system. When objects and people pass through the reader, the reader will automatically scan the information on the label and put the data information input data management information system for storage, analysis and processing to achieve the purpose of controlling logistics.


PDA .jpg

●   The portable data acquisition system uses a handheld PDA  with an RFID reader to collect data on the RFID label. This system has relatively large flexibility and is suitable for the application environment that should not be installed in a fixed RFID system. Intelligent tools allow employees in the store to complete digital work during the work process and improve their work efficiency: for example, employees can quickly read, mark and manage a large number of goods through handheld terminals, in stock, cargo positions, cargo positions Management, goods inquiry, and smart shopping guide can quickly respond to provide customers with more personalized services.



  Video



  FAQ

Q: why should you buy from us not from other suppliers?

A: Leading manufacturer for fiber and copper tester since 1996 Export more than 100 countries Products contain 3 categories R&D team more then 50 person 20,000 square meters workshop CE ISO guaranteed 16 years export experience

Q: How long it will take for delivery?
A: For production lead time around 3-10 days depend on requirement, and shipping time by DHL/UPS/FEDEX/TNT, delivery time would around 3-5 working days. For some remote place, delivery time maybe a little bit longer.

Q: Does the  IP67 Rugged handheld TPDA can read QR code and common 1d bar codes? Support UHF RFID Europe  standard?
A: Yes, if choose 2d scan version, it can read both 1D common code and 2d codes such as QR, PDF417, Data Matrix, PDF417 code...
