ST332B SENTER VDSL2 Tester support 30a,35b profile, can test over 900M

ST332B SENTER VDSL2 Tester support 30a,35b profile, can test over 900M

ST332B VDSL tester is multi-functional hand-held VDSL2 test instrument with small size, specially designed for xDSL line test (xDSL include: ADSL, ADSL2, ADSL2+, READSL, VDSL2 etc) and maintenance It provides xDSL test, PPPoE dial test, DMM test, Modem emulation, line voltage indication and so on. The tester adopts LCD display and menu operation which can display the test results directly and improve the xDSL broadband service greatly. It’s the best choice for the field operators of installation and maintenance.

Product Details

 Key Features

Test objects: ADSL; ADSL2; ADSL2+; READSL; VDSL2 up to 35b, G.Fast

Support Annex A or Annex B, Annex L, Annex M

Fast Copper tests with DMM (ACV, DCV, Loop and Insulation Resistance, Capacitance, Distance)

 Supports Modem emulation and simulating login to Internet

Supports ISP login (username / password) and IP Ping test (WAN PING Test, LAN PING Test)

Supports all multi-protocol, PPPoE / PPPoA (LLC or VC-MUX)

Connects to CO via alligator clip or RJ11

Rechargeable Li-ion Battery

Beep and LEDs alarm indications (Lower Power, PPP, LAN,xDSL)

Data memory fuction

LCD display, Menu operation

Auto shut off if no any operation on keyboard

Compliant with all known DSLAMs

Software management

Simple, portable and money-saved

Functions

DSL Physical layer test

 Modem Emulation (Replace the user Modem completely)

PPPoE Dialing (RFC1683,RFC2684,RFC2516

PPPoA Dialing (RFC2364)

Telephone Function

DMM Test

Ping Function (WAN & LAN)

Data upload to computer and software management

Setup system parameter: backlight time, shut off automatically time without operation, press tone,

Revise PPPoE / PPPoA dial attribute, user name and password; restore factory value and so on.

 Check dangerous voltage

Four grades service judge(Excellent, Good, OK, Poor)


Specifications

ADSL2+





Standards



ITU   G.992.1G.dmt,

ITU   G.992.2G.lite,

ITU   G.994.1G.hs,

ANSI   T1.413 issue #2,

ITU   G.992.5ADSL2+Annex L

Up   channel rate

0~1.2Mbps

Down channel rate

0~24Mbps

Up/Down attenuation

0~63.5dB

Up/Down noise margin

0~32dB

Output power

Available

Error test

CRC,   FEC, HEC, OCD, LCD

Display DSL connect mode

Available

Display channel bit map

Available

ADSL



Standards

ITU G.992.1 (G.dmt)

ITU G.992.2(G.lite)

ITU G.994.1(G.hs)

ANSI T1.413 Issue # 2

Up   channel rate

0~1Mbps

Down channel rate

0~8Mbps

Up/Down attenuation

0~63.5dB

Up/Down noise margin

0~32dB

Output power

Available

Error test

CRC,   FEC, HEC, OCD, LCD

Display DSL connect mode

Available

Display channel bit map

Available

VDSL2

Be compatible with ADSL2+, ADSL   standard.

DSL line attenuation

DSL line noise margin

DSL line up/down channel speed   (Inter/Fast mode)

DSL line up/down maximum rate

DMT sub channel bit number: 015, and each   sub channel frequency points

DSL line error number (CRC, HEC,   FEC, LCD, OCD)

DSL line local output power

DSLAM information

Error Code Second

Impulse Noise Protection (INP)

Support 7 VDSL2 profiles:   profile 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a,35b

G.FAST

Be compatible withVDSL2, ADSL2+,   ADSL standard.

DSL line attenuation

DSL line noise margin

DSL line up/down channel speed   (Inter/Fast mode)

DSL line up/down maximum rate

DMT sub channel bit number: 015, and each   sub channel frequency points

DSL line error number (CRC, HEC,   FEC, LCD, OCD)

DSL line local output power

DSLAM information

Error Code Second

Impulse Noise Protection (INP)

Support 9 VDSL2 profiles: profile   8a, 8b, 8c, 8d, 12a, 12b, 17a,30a,35b

DMM Test

DC voltage (V):

0400

AC voltage (V):

0400

Loop resistance(Ω):

020000

Capacitance (nF):

01000

Insulation resistance (MΩ):

050

General Specification

Power supply

Internal   Rechargeable 2000mAH Li-ion battery

Battery Duration

4   to 5 hours

Working temperature

0-40 oC

Working moisture

5%-90%

Dimensions

180mm×93mm×48mm

Weight:

<0.5kg
