visual fault locator or vfl
Product Features:
--Support CW and 2Hz modulation work mode
--Solid: use special laser end design to avoid damage when dropping on the floor.
--Long working hours: use effective laser drive circuit to ensure 1mW/650nm locator can work more than 50 hours continuously.
--Stable power output: use special laser driver circuit, which can ensure stable power output in the low battery.
--2.5mm universal adapter: use 2.5mm universal adapter, can match SC, FC, ST adapters.
Product Parameters:
Type | ST816B-1 | ST816B-3 | ST816B-10 | ST816B-15 | ST816B-20 | ST816B-25 |
Output Power | 1mw | 3mw | 10mw | 15mw | 20mw | 25mw |
Wavelength | 650nm±10nm | |||||
Light source | LD laser | |||||
Connector | 2.5mm universal adapter | |||||
Working mode | CW or 2Hz modulation | |||||
Operating temperature | -10～+60 °C | |||||
Storage temperature | -20～+70 °C | |||||
Power | 2pcs AA battery | |||||
Working hours | ≥ 50(1mW) | |||||
Weight | 78g（excluding batteries） | |||||
Dimension (mm) | Φ:27; L:168 | |||||
Application and After-Sales Service:
For fiber network, LAN, ATM fiber system and telecom network system.
