ST332B G.FAST Tester



1. Brief Introduction

ST332B tester is multi-functional hand-held G.FAST test instrument with small size, specially designed for xDSL line test (xDSL include: ADSL, ADSL2, ADSL2+, READSL, VDSL2 up to 35b, G.Fast) and maintenance It provides xDSL test, PPPoE dial test, DMM test, Modem emulation, line voltage indication and so on.

The tester adopts LCD display and menu operation which can display the test results directly and improve the xDSL broadband service greatly. It’s the best choice for the field operators of installation and maintenance.


2. Key Features

Ø  Test objects: ADSL; ADSL2; ADSL2+; READSL; VDSL2 up to 35b, G.Fast

Ø  Support Annex A or Annex B, Annex L, Annex M

Ø  Fast Copper tests with DMM (ACV, DCV, Loop and Insulation Resistance, Capacitance, Distance)

Ø  Supports Modem emulation and simulating login to Internet

Ø  Supports ISP login (username / password) and IP Ping test (WAN PING Test, LAN PING Test)

Ø  Supports all multi-protocol, PPPoE / PPPoA (LLC or VC-MUX)

Ø  Connects to CO via alligator clip or RJ11

Ø  Rechargeable Li-ion Battery

Ø  Beep and LEDs alarm indications (Lower Power, PPP, LAN,xDSL)

Ø  Data memory fuction

Ø  LCD display, Menu operation

Ø  Auto shut off if no any operation on keyboard

Ø  Compliant with all known DSLAMs

Ø  Software management

Ø  Simple, portable and money-saved


3. Functions

Ø  DSL Physical layer test

Ø  Modem Emulation (Replace the user Modem completely)

Ø  PPPoE Dialing (RFC1683,RFC2684,RFC2516

Ø  PPPoA Dialing (RFC2364)

Ø  Telephone Function

Ø  DMM Test

Ø  Ping Function (WAN & LAN)

Ø  Data upload to computer and software management

Ø  Setup system parameter: backlight time, shut off automatically time without operation, press tone,

Ø  Revise PPPoE / PPPoA dial attribute, user name and password; restore factory value and so on.

Ø  Check dangerous voltage

Ø  Four grades service judge(Excellent, Good, OK, Poor)

4. Specifications

ADSL2+





Standards





ITU G.992.1G.dmt,

ITU G.992.2G.lite,

ITU G.994.1G.hs,

ANSI T1.413 issue #2,

ITU G.992.5ADSL2+Annex   L

Up channel rate

0~1.2Mbps

Down channel rate

0~24Mbps

Up/Down attenuation

0~63.5dB

Up/Down   noise margin

0~32dB

Output   power

Available

Error   test

CRC, FEC, HEC, OCD, LCD

Display   DSL connect mode

Available

Display   channel bit map

Available

ADSL



Standards

ITU G.992.1 (G.dmt)

ITU G.992.2(G.lite)

ITU G.994.1(G.hs)

ANSI T1.413 Issue # 2

Up channel rate

0~1Mbps

Down channel rate

0~8Mbps

Up/Down attenuation

0~63.5dB

Up/Down   noise margin

0~32dB

Output   power

Available

Error   test

CRC, FEC, HEC, OCD, LCD

Display   DSL connect mode

Available

Display   channel bit map

Available

VDSL2

Be compatible with ADSL2+, ADSL standard.

DSL line attenuation

DSL line noise margin

DSL line up/down channel speed (Inter/Fast   mode)

DSL line up/down maximum rate

DMT sub channel bit number: 015,   and each sub channel frequency points

DSL line error number (CRC, HEC, FEC, LCD,   OCD)

DSL line local output power

DSLAM information

Error Code Second

Impulse Noise Protection (INP)

Support 7 VDSL2 profiles: profile 8a, 8b,   8c, 8d, 12a, 12b, 17a, 30a,35b

G.FAST

Be compatible withVDSL2, ADSL2+, ADSL   standard.

DSL line attenuation

DSL line noise margin

DSL line up/down channel speed (Inter/Fast   mode)

DSL line up/down maximum rate

DMT sub channel bit number: 015,   and each sub channel frequency points

DSL line error number (CRC, HEC, FEC, LCD,   OCD)

DSL line local output power

DSLAM information

Error Code Second

Impulse Noise Protection (INP)

Support 9 VDSL2 profiles: profile 8a, 8b,   8c, 8d, 12a, 12b, 17a,30a,35b

DMM Test

DC voltage (V):

0400

AC voltage (V):

0400

Loop resistance(Ω):

020000

Capacitance (nF):

01000

Insulation   resistance (MΩ):

050

General Specification

Power   supply

Internal Rechargeable 2000mAH Li-ion   battery

Battery   Duration

4 to 5 hours

Working   temperature

0-40 oC

Working   moisture

5%-90%

Dimensions

180mm×93mm×48mm

Weight:

<0.5kg
